FTTH Outdoor Fiber Terminal Box 16 fibers (FTT-H308)

• The high strength plastic, anti-ultraviolet radiation and ultraviolet radiation resistant, resistant to rain
• For indoor and outdoor overhead and hang wall use
• Box of body use \"lock type\" structure, box of body switching of simple, convenient, with a lock function safe use
• Melt receive flip type design simple to use, melting with complete separation of fine points fiber layout more reasonable
• Industry standard user interface, be made of high impact plastic.
• Can accommodate 1x8 & 1x16 PLC splitter;
• Anti-UV, Ultra violet resistant and rainfall resistant;
• Up to 16 FTTH drops
• Wall and pole mountable;
• 2 inlet ports, 16 outlet ports

1. Temperature: -40℃—60℃
2. Ambient Humidity : 95% above 40℃
3. Air pressure: 62kPa—105kPa

1. 2 hoops (outdoor air frame) Optional
2. wall mount kit 1 set
3. two lock keys used waterproof lock

• Widely used in FTTH access network.

• Telecommunication Networks

• CATV Networks

• Data communications networks

• Local Area Networks (LANs)
