Factory Supply GJFJH 2 Core Duplex Indoor Optical Cable 2.0mm/3.0mm Twin Tight Buffer Fiber with Aramid Yarn High Tensile Strength
|
No. of cable |
2 |
|||
|
Tight lines |
Material |
PVC/LSZH |
||
|
Thickness（±0.03）mm |
0.32 |
|||
|
Diameter（±0.06）mm |
0.9 |
|||
|
Colour |
White |
|||
|
Strength Member |
Material |
Aramid Yarn |
||
|
Outer Sheath |
Material |
PVC/LSZH |
||
|
Thickness（±0.05）mm |
0.35 |
0.45 |
||
|
Cable Diameter（±0.2）mm |
2.0 |
3.0 |
||
|
Cable Wetght（±2）kg/km |
7.8 |
13.5 |
||
|
Allowable Tensile Strength |
Short Term |
N |
300 |
|
|
Long Term |
160 |
|||
|
Allowable Crush Resistance |
Short Term |
N/100mm |
1000 |
|
|
Long Term |
200 |
|||
|
Min. bending radius |
Without Tension |
10.0D |
||
|
Under Maximum Tension |
20.0D |
|||
|
Temperature range （℃） |
Installation |
-20~+60 |
||
|
Transport&Storage |
-20~+60 |
|||
|
Operation |
-20~+60 |
|||
|
Optical Fiber |
G652D |
G657A1 |
A1b(62.5/125um) |
OM2(50/125um) |
OM3-300(50/125um) |
OM4(50/125um) |
|
Wavelength(nm) |
1310/1550 |
1310/1550 |
850/1300 |
850/1300 |
850/1300 |
850/1300 |
|
Attenuation |
0.8/0.6 |
0.4/0.3 |
3.5/1.5 |
3.5/1.5 |
2.8/0.7 |
2.5/0.7 |
|
Bandwidth |
- |
- |
200~800/200~1200 |
160~800/200~1000 |
≥700/≥500 |
≥1500/≥700 |
|
Colour Of Outer Sheath |
Yellow |
Yellow |
Orange |
Orange |
Aqua |
Violet |
